EVE G11E 3.7V 31.9AH 32.4Ah 46950 Cylindrical NCM Cell Discharge 6C High Energy Density Manufacturing Factory OEM ODM
Brand: HAICHEN
MOQ: 2 Pieces
Delivery time: 15 Day
EVE 31.9Ah 32.4Ah 46950 (G11E)
Energy Density: Up to 290 Wh/kg
Discharge Rate: Supports 6C high-rate discharge
31.9Ah 32.4Ah 3.7V
Widely Application
Product Details
EVE G11 3.7V 31.9AH 32.4Ah 46950 Cylindrical NCM Cell Discharge 6C High Energy Density Manufacturing Factory OEM ODM
|
Product Name:
|
EVE 31.9Ah 46950 (G11E)
|
|
|
Nominal Capacity(Ah):
|
31.9Ah 32.4ah
|
|
|
Nominal Voltage(V):
|
3.7V
|
|
|
Operation Voltage：
|
2.5~4.2V
|
|
|
Weight(Approximate):
|
433g
|
|
|
Battery Cell:
|
Grade A 314/304/302/280Ah new cell
|
|
|
Dimensions:
|
Diameter :46mm Height:95mm | |
|
Standard Cycle life:
|
1000 cycles ≥ 80% | |
|
Standard Discharge 25°C
|
Standard current:
|
10.63A, 1/3C
|
|
Max.10sec.pulse:
|
189.5A (25°C, 50%SOC, 10s)
|
|
|
Standard Charge 25°C
|
Standard Current: |
10.63A,1/3C
|
| Max. cont. current: |
82.9A
|
|
|
Operation Temperature:
|
Discharge -35℃~ 60℃; Charge 0℃~ 50℃
|
|
|
SOC Range:
|
5%-100%
|
|
Key Features
-
Model: EVE 31.9Ah 32.4ah 46950 (G11E)
-
Voltage: 3.7V
-
Capacity: 31.9Ah 32.4ah
-
Energy Density: Up to 290 Wh/kg
-
Discharge Rate: Supports 6C high-rate discharge
-
Form Factor: Cylindrical design, compact and flexible for installation
